Passion fruit processing plant special industrial juice beverage production line
Industrial Passion Fruit Processing Line
Tailored for the unique operational needs of passion fruit processing plants, this versatile processing line delivers a streamlined, high-efficiency solution for converting fresh passion fruits into diverse premium products. From the initial raw material cleaning and sorting stage, to the precise pulping, seed separation, concentration, and sterilization processes, every step is optimized to preserve the passion fruit’s natural flavor, nutritional value, and vibrant color—yielding top-tier products such as pure NFC juice, concentrated pulp, spreadable jam, and functional beverage additives. Beyond its production versatility, the line is built with food-grade SUS304 stainless steel and integrated with intelligent quality control systems, ensuring that every batch of products strictly complies with rigorous food safety standards. For passion fruit processing plants seeking to enhance production flexibility, reduce operational costs, and uphold the highest food safety benchmarks, this processing line stands as a reliable, future-proof investment that adapts to evolving market demands.
Process Flow
- Raw Material Management: Cleaning & sorting with wave-type and brush washers
- Preprocessing: Peeling, seed removal, cutting, and pulp extraction
- Versatile Processing: Juice production, jam making, dried fruit, wine crafting, and preserved fruit
- Packaging & Storage: Automated grading, metal detection, and coding
Technical Specifications
| Raw material |
Passion fruit |
| End product |
Pulp, puree, jam, juice, beverage, etc. |
| Processing capacity |
From 3 T/day to 1500 T/day (raw material) |
| Juice yield |
40% raw fruit (60% as waste, peels and seeds) |
| End package |
Aseptic bag, metal can, glass bottle, PET bottle, etc. |
Key Features
Modular design with 304 stainless steel components for superior sanitation
High automation level with PLC-controlled processes
Flexible packaging options including aseptic filling
Energy-efficient operation with CIP cleaning system
Main Equipment
- Washing and Sorting Machine (multiple types available)
- GFM-FD series fruit destoning machine
- Pulper & Refiner for seed separation
- Evaporator/Concentration systems (forced circulation and falling film)
- Adjustable sterilizer with UHT capability
- Automatic aseptic filling machine
Processing Line Options
Juice Production: FRESH PASSION FRUIT ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ DESTONING ⇒ PULPER & REFINER ⇒ STERILIZING ⇒ ASEPTIC FILLING
Juice Concentrate: FRESH PASSION FRUIT ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ DESTONING ⇒ PULPER & REFINER ⇒ EVAPORATING ⇒ STERILIZING ⇒ ASEPTIC FILLING
Our Services
Spare Parts: Comprehensive inventory for minimal downtime
On-Site Assistance: Timely technical support worldwide
Training: Comprehensive operator and maintenance training programs
About Gofun Machinery
Shanghai Gofun Machinery Co., Ltd. specializes in turnkey solutions for food processing lines, with extensive experience in fruit and vegetable processing equipment. Our passion fruit processing lines combine imported core components with domestic manufacturing excellence, delivering reliable performance and industry-leading after-sales service.
