Complete Mango Processing Line | From Fresh Fruit to Aseptic Puree & Juice Concentrate

起源の場所	上海
ブランド名	Gofun
証明	CE, ISO certificate
モデル番号	gfm-mpl

製品詳細

保証:

12ヶ月

証明:

CE/ ISO9001

電圧:

顧客によると、220/380/440V

電力(w):

7.5kw

タイプ:

AからZまでのターンキー処理ライン

材料:

SUS304/ SUS316

容量:

1 t/h-20 t/h

製品名:

マンゴー乾燥加工機

アフターサービス:

海外の技術サポート

応用:

マンゴー

状態:

新しい

重さ:

カスタマイズされた

支払いと送料の条件

最小注文数量

1セット

価格

negotiable

パッケージの詳細

輸送用の国際標準パッケージ

受渡し時間

45〜90日

支払条件

T/T、ウェスタンユニオン、L/C

供給の能力

年間100セット

製品説明

Complete Mango Processing Line – Turnkey Solution for Juice & Puree Manufacturing

From Fresh Fruit to Aseptic Filling – One Supplier, One Responsibility

Investing in a mango processing plant is a significant decision. You need a partner who delivers more than just machines. You need a complete, worry-free solution that takes you from raw fruit to market-ready product.

Our turnkey mango processing line is designed for investors who want to start production quickly, efficiently, and without technical headaches. We handle everything: factory layout design, equipment manufacturing, installation supervision, commissioning, and local training for your team.

What You Get with Our Turnkey Service:

Custom Factory Design – We analyze your available space, target capacity (1-100TPH), and final product requirements to create an optimal layout.

Complete Equipment List – Washing, sorting, peeling, crushing, enzymatic treatment, refining, vacuum deaeration, UHT sterilization, and aseptic bag filling.

Material Quality – All contact parts are SUS304 or SUS316L stainless steel, compliant with international food safety standards.

Installation & Training – Our engineers travel to your site for installation guidance and operator training. No prior technical experience required.

After-Sales Support – 12-month warranty, lifetime technical support, and fast spare parts delivery.

Products You Can Produce:

Mango NFC juice (not from concentrate)

Mango puree for beverage blending

Mango concentrate (adjustable Brix)

Mango pulp for yogurt, ice cream, or baby food

Capacity Options:

From 1 ton per hour for small-scale startups to 100 tons per hour for industrial export factories. Modular design allows future expansion without replacing existing equipment.

Why Choose Our Turnkey Line?

You don't need to coordinate with multiple suppliers for washers, crushers, evaporators, and fillers. We deliver a fully integrated line engineered to work as one system. Every component is pre-tested before shipment. You get one point of contact, one warranty, and one team dedicated to your success.

Ready to build your mango processing factory? Request a free layout design and capacity recommendation today.

Technical Specifications

Product Name	One-stop solution for mango processing line
Fresh Fruit Inlet Capacity	500kg per hour ~ 25 tons per hour, customized
Raw Material	Fresh mango
End Products	Mango pulp puree, Mango concentrate, Mango sauce, Mango juice, Mango beverage
Final Product Brix	14%~20%
Final Package Options	Aseptic bag, Aluminum can, Stand-up pouch, PP container, Plastic bottle, Glass jar, Gable top carton box, Tetra pack, etc
Machine Material	Food grade SUS304 or SUS316
Warranty	12 months after commissioning
Operator Requirement	About 10~12 persons
Voltage	380V 50Hz/ 110V 60Hz/ 415V 50Hz (adjustable to client's country standard)
Advantages	Energy-saving, High efficiency, Water-saving, Stable performance

Processing Flowchart

FRESH MANGO ⇒ CONVEYOR ⇒ WASHING ⇒ SORTING ⇒ DESTINING ⇒ PREHEATING ⇒ PULPING & REFINING ⇒ CENTRIFUGE ⇒ STERILIZING ⇒ ASEPTIC FILLING ⇒ STORAGE OR BLENDING

Final Products & Packaging Options

Our processing line utilizes fresh mango and mango paste as raw materials to produce various final products including mango paste, mango sauce, mango juice, mango powder, diced mango, and dried mango.

Available packaging formats include aseptic bags, metal cans, sachets, stand-up pouches, PP containers, glass bottles, PET bottles, and gable top cartons.

Key Features

Full-process Integration: Comprehensive mango processing from pretreatment to bottling of finished products within a single integrated system
Safety Assurance: Built with 304/316 stainless steel and FDA/CE certification for ensuring food safety standards
Smart and Productive: Precise parameter control via PLC with adjustable capacity ranging from 500kg/h to 10t/h
Energy-efficient and Eco-friendly: Low-power configuration to minimize operational expenses
Versatile Functionality: Capable of processing mango pulp, various juices, and vegetable purees
Complete Support: Tailored design, installation, commissioning, technical training, and post-sales assistance services

Detailed Process Steps

1. Discharge Platform

Specialized drainage platform with water guns simplifies raw mango unloading from trucks while providing pre-washing capabilities to enhance production line efficiency.

2. Elevator

This machine transports fresh mango from outside the building to inside the processing facility.

3. Washing

Thorough washing of fresh fruits prior to crushing using bubble washers and brush & spray washers. Optional ultrasonic and ozone cleaning methods available for enhanced cleaning efficacy.

4. Sorting

Visual inspection by staff after washing to identify defects, ensuring only high-quality fruits proceed through the production line.

5. Destoning

Mango remover operates at 1470 r/min, effectively crushing fresh mango to ensure thorough cleaning of core and skin, maximizing pulp yield and production efficiency.

6. Preheating

Adjustable temperature pre-heater (45℃ to 85℃) increases juice yield for subsequent processing while protecting final product color and taste.

7. Pulper and Refiner

Operating at 1470 r/min, this machine generates centrifugal force to pass product through screens for refinement. Suitable for various fruits including passion fruit, tomatoes, peaches, apricots, mangoes, and apples.

8. Horizontal Spiral Centrifugal

Reduces solids and impurities to ensure mango pulp puree is free from contaminants and black spots.

9. Sterilizing

Tube-in-tube type sterilizer with adjustable temperature and retention time for different product requirements. Programmable control system ensures precise automation.
